Energy Projects

Oil, Gas & Petrochemical

Construction of Bushehr Methanol Plant & C2 Recovery

Bushehr Petrochemical Company Methanol Plant has been designed with a capacity of 3.3 million tons Methanol per year.
The feedstock for Plants production will be supplied by phases 6, 7 and 8 of south pars gas field.
The onus on the Rampco to execute Construction in all disciplines including Mechanical instalation, Electrical and Instrumentation, Painting, Insulation, Safety Equipment, Necessary civil works, Testing, Precommisioning, and Commisioning of Bushehr Petrochemical Company Methanol Plant.

Static Equipment: 13,170 ton
Rotary Equipment: 807 ton
WoID of Piping: 304,000 iD
Steel Structure: 4,560 ton
Client: Bushehr Petrochemical Company
Year: 2015-2017


EPC contract of HDPE Plant Mehr

RAMPCO and MES Joint Venture have been Awarded to Execute an EPC Project to Establish a HDPE Unit in Assaluye Extended in an area of 13 hectares, with capacity of 300,00 ton/y within 3 years. The Joint venture perfume this contact with implementation of 135 years engineering experience of MES and Procurement and Construction strength of RAMPCO without even an hour delay. Mehr petrochemical with receiving of 305 Mton/y and 3000 ton Butene and having process such as polymerization, Distillation and Hegzane concentrating is able to produce granule High Density Poly Ethylene (HDPE) . HDPE as one of the main product of petrochemical industries is commonly used in the production of plastic bottles, corrosion-resistant piping, geomembranes, and plastic lumber. According to the contact, RAMPCO and MES as the contractor was to Basic and Detailed Engineering, Procurement, Construction, Pre-commission Commissioning of an HDPE Plant with capacity of 300,000 ton/y accompanied by its off-site and utility units. In all disciplines piping, process, electrical , instrument, civil, insulation, paint of all process units such as Catalyst Preparation Unit, Reformer and Reactor Units.

Excavation: 73,853 m3
Rebar Wor: 2,100 Ton
Concrete Work: 20,596 m3
Frame work: 41,327 m2
Steel Structure: 3,408 Ton
Area of Building: 26,558 m2
WID of Piping: 270,000 ID
Weight of Erected Equipment: 2,956 Ton
Total Construction Man-Hour: 4,500,000 Man-Hour
Client: Mehr Petrochemical Co.
Year: 2005-2009


 Construction of Kavian Petrochemical Co.

Kavian Petrochemical Company, is the largest olefin plant in the world with 2,000,000 Ton Ethylene production.  RAMPCO has a major construction contract for furnace and rotary and static equipment erection, electrical and instrument installation including activities on process and offsite unit. The project is executed in Pars special economic energy zone. (PSEEZ) According to this contract RAMPCO was to purchase, manufacture, construct and Install 2 train of Kavian Petrochemical Plant and handover the plants after performing pre-commissioning and commissioning. Also Rampco was responsible to procurement and installation of Instrument and Insulation in Olephin Unit I and II in Kavian Plant. Construction and procurement of rotating and static, electrical and instrument equipment and installation of furnaces of olefin 1, 2 units. Installation of cold and warm Insulator was the core activity in this contract.

Location: P ll, Assaluyeh
Area: 42.8 Hectare
Equipment Erection: 66,928 Ton
Insulation: 150,925 m²
Piping Operation: 209,525 iD
Painting Operation: 398,922 m²
Total Work: 9,305,137 Man-hour
Client: Kavian Petrochemical Co.
Year: 2008-2011


 Sirri Island F&G System EPC Project

Iranian Offshore Oil Company intends to do design and construction, procurement and supply of materials, equipment, and project machinery, construction of firefighting network, addressable fire detection and fire extinguishing system, improving existing fire detection and fire extinguishing system and preparing safety requirements for facilities and equipment on Sirri Island.

Client: Iranian offshore oil company
Year: 2014-2016

Kerman Tank Farm EPC Project

In 2007, RAMPCO became responsible to execute an EPC project in order to Construct a new tank farm in Kerman suburb for storage and supply oil products of this city. N.I.O.P.D.C planned to construct a tank farm with total storage capacity of 325,000 cubic meters which accompanied by other required accessories such as loading system, including top and bottom loading arms and pump sheds, transportation system, control and firefighting system. The onus on the RAMPCO to Construct Kerman Tank Farm including Basic and Detailed design and Engineering service, Procurement, mobilization and executing the construction works, pre-commissioning and commissioning in all disciplines such as civil, process, mechanical, Instrument, electrical, off-site facilities provision and so on.

Location: Iran-Kerman
Area: 60 Hectare
Number of Tanks: 15 Tanks
Total Capacity of Tanks: 350,000 m3
Manpower during operation: Direct 273, Indirect 70
Project duration: Around 36 months
Weight of Erected: Equipment’s 10,000 Ton
Total Construction: Man– Hour 3,150,000 Man-Hours

Client: National Iranian Oil Products Distribution Co.
Year: 2007

Omidiye Pump Station EPC Project

This Pump Station has been designed to Collect and Transfer the Oil and Gas that Product from Azadegan, North Azadegan, Yadavaran and Jafir fields to the utilization units. This Pump Station used to Transfer the Oil and Gas along a 257 Km and 32-inch Pipeline from Azadegan to Behregan. Engineering, procurement, construction, installation and commissioning of project of transferring the light and heavy oil west of the country. We used heavy duty electro pump with 21+ makeup in Omidiye station, it transfers heavy oil with 32 inch pipe line to Behregan station in boshehr province. After metering in Behragan it go to export.

Subject: Construct a tank farm with total storage capacity of 325,000 m2
Facilities Area: 3,3 Hectare
Total Work: 400,000 Man-Hour

Client: Petroleum Engineering & Dev Co.
Year: 2007





Power & Steam Generation Plants

Water Tube Boiler for HASHEMINEJAD Gas Treatment Plant
According to this contract RAMPCO as the contractor was to design, construct and install boiler for NIGC. This including installation boiler with capacity of 90 ton/hr and A type. We are also responsible for commissioning, pre-Commissioning of boilers and procurement of auxiliary equipment.
Capacity: 1 x 90 ton/hr
Pressure: 36 Barg
Temperature: 321°C
Client: Iranian Gas Engineering and Development Co.
Year: 2010



Water Tube Boiler for KERMANSHAH Petrochemical Complex

In 2012, RAMPCO has been awarded to furnish for procurement of one steam generator boiler with capacity of 75 ton/hr for Kermanshah complex. This project includes 75 ton/hr water tube steam D type boiler and its complete auxiliary equipment for installation in petrochemical Plant.

Capacity: 1 x 75 ton/hr
Pressure: 43 Barg
Temperature: 420°C
Client: Kermanshah Petrochemical Complex
Year: 2012


Water Tube Boiler for HASHEMINEJAD Gas Treatment Plant
According to this contract RAMPCO as the contractor was to design, construct and install boiler for NIGC. This including installation boiler with capacity of 90 ton/hr and A type. We are also responsible for commissioning, pre-Commissioning of boilers and procurement of auxiliary equipment.

Capacity: 1 x 90 ton/hr
Pressure: 36 Barg
Temperature: 321°C
Client: Iranian Gas Engineering and Development Co.
Year:
2010


Water Tube Boilers for KORDESTAN Petrochemical Company
In 2011, RAMPCO planned to execute a project in order to supply equipment, commissioning, start up and performance test for steam generation unit.
Erection, pre-commissioning, commissioning and performance test of 2 units. Each with capacity of 30 ton/hr and O type including major equipment of steam drum, water steam drum, water wall tube, economizer tube, burners, BFW pumps, super-heated tube.

Capacity: 2 x 30 ton/hr
Pressure: 41 Barg + 7 Barg
Temperature: 420°C + 180°C
Client: Kordestan Petrochemical Co.
Year:
2011


Water Tube Boilers for MORVARID Petrochemical Complex

1*60T/H & 2*30T/H Water Tube Steam Boiler for Morvarid Petrochemical Complex.
Project duration: 8 months
Boiler Type: O-type
Scope of Supply: Two (2) 30TPH +One (1) 60TPH Water tube Boiler - 6 Drums
Burner*4
Control System*1
Deaerator*3
Super heater*3
Economizer*3
Stack*3
BFW Pump*7

Client: Morvarid Petrochemical Co.
